Application engineering note
The LONGWELL LWT35-4.5-002 drawing describes an AC axial fan in a cylindrical housing. Its electrical requirements and flanged mounting geometry should be checked together when specifying an industrial ventilation assembly.
What the drawing specifies
| Parameter | Drawing value |
|---|---|
| Supply | 380 VAC, 50 Hz |
| Speed | 1450 rpm |
| Input power | 550 W |
| Airflow | 10,400 m³/h |
| Static pressure | 217 Pa |
The sheet lists these airflow and pressure figures without a full performance curve. Request the operating-point information needed to check the fan against the actual duct, grille and equipment resistance.
Mechanical integration
The housing drawing shows a 340 mm axial length, a 520 mm outside flange diameter and six 10 mm mounting holes. Check the flange and hole arrangement against the mating structure, including intake clearance, outlet transitions and service access.
Use the electrical supply printed on the selected drawing when preparing the installation specification. A different voltage or frequency requires its own confirmed motor and performance data. For a comparison between LWT35 sizes, obtain each model’s drawing rather than transferring one model’s dimensions or ratings to another.
A complete enquiry should identify the required airflow and pressure at the same operating condition, along with installation orientation and the expected air temperature.
Discuss your fan requirement
Send LONGWELL your airflow and pressure duty point, power supply, available installation space, control requirements, operating environment and drawings. Contact our engineering team to discuss a suitable configuration.
