3D CAD Modeling for Cross Flow Fans
On June 24, 2026, LONGWELL opened a project to provide 3D CAD model deliverables for two cross flow fan models: LWCA-50150SN-07 and LWCA-50190SN-07. The customer requested 3D geometry files to support mechanical integration and spatial evaluation within their equipment enclosure.
On June 24, 2026, LONGWELL engineering reviewed the standard fan specifications and generated the corresponding 3D STEP models (LWCA-50150SN-07.stp and LWCA-50190SN-07.stp) for technical evaluation.
Project Deliverable Summary
| Project Attribute | Details |
|---|---|
| Fan Category | Cross flow fan |
| Target Models | LWCA-50150SN-07, LWCA-50190SN-07 |
| Requested Deliverables | 3D CAD models (STEP format) |
| Project Opening Date | June 24, 2026 |
| Engineering Completion Date | June 24, 2026 |
The engineering output for this stage consisted of completed 3D STEP models ready for mechanical fit checks and enclosure placement reviews.
