On April 9, 2026, LONGWELL opened a project to provide a fan configuration based on a DD7-7 double-sided guard requirement, offering an LWFA series double inlet centrifugal blower solution. LONGWELL engineering prepared the specification and layout drawing to meet the required operating parameters under model designation LWFA-E-200-02.

Reference fan enclosure and wiring arrangement included with the double-guard request
Reference fan enclosure and wiring arrangement included with the double-guard request.

Specified Technical Parameters and Dimensions

Engineering outputs finalized on April 10, 2026, established the baseline mechanical dimensions and electrical performance criteria for model LWFA-E-200-02, incorporating double-sided mesh guards on the housing inlets.

Parameter Label Specified Value
Voltage (VAC) 230
Frequency (Hz) 50
Power Input (W) 250
Speed (RPM) 1354 ± 10%
Airflow (m³/h) 1000 – 1300
Static Pressure (Pa) 305 – 300
Protection Rating IP44
Overall Width / Height (mm) 319 / 369
Flange Mounting Pattern (mm) 258 x 162 (8-Ø8 holes)

Engineering Deliverable Output

LONGWELL engineering completed specification sheet and technical drawing LWFA-E-200-02 on April 10, 2026. The finalized drawing defines the physical envelope and mounting layout for customer fit evaluation.

Drawing excerpt from the engineering file prepared for this request
Engineering drawing excerpt for the requested configuration.

Discuss a Similar Fan Requirement

If you require custom inlet guard configurations, flange mounting adjustments, or specific airflow performance profiles on a double inlet centrifugal blower, share your technical requirements with our engineering team.

Provide your target duty point, operating voltage, physical envelope constraints, and protective guard preferences via LONGWELL Contact or evaluate model options on LONGWELL Fan Selector.
