On July 22, 2026, LONGWELL opened an engineering project to update an existing cross flow fan configuration. The revised requirement specified a 48V DC operating voltage with an updated nominal speed of 2900 RPM. In response, LONGWELL engineering reviewed the configuration and prepared the revised technical drawing and specification under model number LWCD-45190HN-07-00 on July 23, 2026.
Technical Specifications and Physical Envelope
| Parameter | Specification |
|---|---|
| Model Number | LWCD-45190HN-07-00 |
| Nominal Voltage | 48 VDC |
| Nominal Speed | 2900 ± 10% r/min |
| Bearing Type | Ball bearing |
| Impeller Diameter & Material | Ø45 mm, Aluminum |
| Dimensions | 190 mm outlet / 210±1.5 mm housing / 252±2 mm overall width |
Request Technical Evaluation for Similar Applications
If your project requires customized DC cross flow fans, specific speed curves, or custom wiring harnesses, please provide your operating duty points and physical envelope details through our contact page or explore additional configurations using the LONGWELL fan selector tool.
