24V DC axial fan specification overview

The requirement was for a standard specification document for model LWAD9225MX-24-00. On June 30, 2026, LONGWELL opened a project to compile and issue the technical documentation. The specification sheet was prepared by LONGWELL engineering and completed review on July 1, 2026.

Illustration of a compact square-frame axial cooling fan with corner mounting holes
Illustration of a compact axial fan type.

Technical and electrical performance parameters

The LWAD9225MX-24-00 axial fan is designed for a nominal 24.0 VDC supply with an operating voltage range of 12 to 26.5 VDC. Construction features include dual ball bearings with PBT plastic housing and impeller rated to UL 94V-0 standards.

Specification Parameter Value / Description
Model Number LWAD9225MX-24-00
Rated Voltage 24.0 VDC
Operating Voltage Range 12 to 26.5 VDC
Input Current 0.2 A (Max 0.25 A)
Input Power 4.8 W (Max 6.0 W)
Nominal Speed 3850 RPM (±10%)
Maximum Drawing air-volume value (at 0 Static Pressure) 72.16 CFM (Min 64.94 CFM)
Maximum Static Pressure (at 0 Air Flow) 2.62 mm H2O
Average Acoustical Noise 42.0 dBA (Max 45.0 dBA)
Unit Weight 75 grams

To view the full design documentation, refer to the LWAD9225MX-24-00 Technical Specification Sheet.

Drawing excerpt from the engineering file prepared for this request
Engineering drawing excerpt for the requested configuration.

Discuss a similar requirement

If you require detailed performance specifications, customized lead wire lengths, or mechanical modifications for 24V DC axial fans, provide your target duty point, operating voltage range, and mounting requirements to our engineering team through our contact page or explore parameters using the LONGWELL Fan Selector Tool.
