On July 21, 2026, LONGWELL opened a project to provide standard drawings and technical specifications for the LWPVL-1270T-01 axial fan model based on customer requirements.

Axial fan with a circular wire guard and metal blades
Representative guarded axial fan; project specifications are listed below.

Input Requirements and Design Specifications

The standard specifications feature an operating voltage of 380 V with an airflow output of 51,000 m³/h at 80 Pa. On July 21, 2026, LONGWELL engineering completed the standard technical drawing and specification output for the LWPVL-1270T-01 model.

Parameter Label Value / Specification
Blade Diameter 1270 mm
Voltage / Frequency 380 V / 50 Hz
Import Power 1.1 kW
Total Pressure 80 Pa
Air Flow 51,000 m³/h
Housing Material Galvanized sheet
Impeller Material Stainless steel
Wind Cone Material Galvanized sheet
Overall Height (A01) 1380 mm
Overall Width (A02) 1380 mm
Cone Outlet Diameter (A03) Ø1300 mm

Technical Scope and Output

Engineering completed the drawing and technical specification document (LWPVL-1270T-01.pdf) on July 21, 2026, establishing the structural dimensions and specified electrical and performance parameters for fit and application evaluation.

Drawing excerpt from the engineering file prepared for this request
Engineering drawing excerpt for the requested configuration.

Discuss a similar requirement

If you require axial fans tailored to specific airflow, static pressure, or mounting dimensions, contact LONGWELL engineers. Provide your operating point, power constraints, and housing requirements via the LONGWELL contact page or search standard options on the LONGWELL fan selection platform.
