Description
Technical Description
| Technical Feature | 1.Large air volume,low vibration and low noise.Laser cutting blanking greatly improves the accuracy of the product,and the shape is beautiful and generous. 2.YE series of high-efficiency and energy-saving motors are used in the motor,with high efficiency,low energy consumption,good quality and long service life. 3.Widely used in industrial and mining enterprises,large buildings,factories,hotels,restaurants and other indoor and outdoor ventilation. 4.Particularly suitable for heating furnace,hot blast stove,drying,chemical industry,food,grain machinery and other related industries. 5.Optional high temperature resistant extended shaft motor,high temperature resistant 200℃. |
Nominal data
| Dimensions | / |
| Voltage | 380V/380V |
| Frequency | 50Hz/50Hz |
| Power | 1.1KW-47.5KW-2 |
| Speed | 1450r/min/2900r/min |
| Total Head | 634-416Pa/2554-1673Pa |
| Air Flow | 2856-5281m³/h/5712-10562m³/h |
| Noise | / |
Curves
Drawing
Download
The Company Longwell Leading Fan and Motor Innovator Worldwide
As a leading supplier of ventilation and drive technology, LONGWELL is a highly respected engineering partner in many industries. With over than 20,000 different products, we provide the right solution for every need. And we have always worked according to the highest economic and ecological standards.
As part of the logical next step in the development of our high-efficiency BLEC MOTOR technology, we believe that industrial digitalization offers the best prospects for our customers in the future. LONGWELL already offers intelligently interconnected complete solutions that are second to none worldwide and ensure that our customers always remain that decisive step ahead.
