LONGWELL DC Backward Curved Centrifugal Fan, Industrial Centrifugal Blower, 230V, Low Noise, for AHU, Air Purifiers, HVAC Systems – LWBE3G355

Name: LONGWELL DC Backward Curved Centrifugal Fan, Industrial Centrifugal Blower, 230V, Low Noise, for AHU, Air Purifiers, HVAC Systems – LWBE3G355
Brand: Ningbo Longwell Electric Technology Co., Ltd.

Voltage 230V,400V

ISO / CE / UL / ETL Factory & Test Lab OEM / ODM ebm-papst alternative

$ 100

Specifications

Motor: EC external rotor motor
Speed: 2800rpm, 2600RPM, 2450RPM
Impeller: Aluminum alloy

Category: Backward Curved Centrifugal Fans Tags: Air Purifier, Backward Curved Centrifugal Fan, EC Motor

CategoryBackward Curved Centrifugal Fans

TagsAir Purifier Backward Curved Centrifugal Fan EC Motor

Get a Fast Quote from an Engineer Send your airflow, static pressure & voltage — we reply within one working day with a matching model.

✓ 1-day reply ✓ STEP / CAD on request ✓ Factory-direct

Name

Work Email

Phone / WhatsApp

Estimated order quantity

Message

This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

Your specifications go straight to a sales engineer — no spam, never shared.

Prefer a datasheet?

Download Product Catalog (PDF)

Need the exact model with a measured or digitised curve? This page describes the Backward Curved Centrifugal Fans range. The Fan Selector lists every LONGWELL backward-curved centrifugal fan model with airflow, static pressure, power, noise, drawing and datasheet.

Search backward-curved centrifugal fan models →

Description

Product Name	LONGWELL 24V DC Backward Curved Centrifugal Fan – Low Noise Cooling for Air Purifier/Kitchen
Types :	355mm EC high quality PWM speed control ECM motor 3000cfm continuously Speed exhaust fan 3 phase centrifugal fan
Voltage Ranges :	230V,400V;
Frequency :	50/60 Hz
Diamter :	355mm ( impeller diameters )
Motor Types :	BLEC External Rotor Motor ( EC )
Speed Control :	0-10V Signal / PWM / RS485(Optional)
Max.ambient Temp:	-25℃～ +60℃
Certificating :	All necessary certifications suitable for USA & Europe , ETL,UL ,CE ,RoHS, ISO19001,ISO 14001,BSCI
Protection Level:	IP44 ,IP54,IP55
Electronic Protection:	Current limiting protection ,Over-temperature protection,Over-current protection,Locked-rotor protection,Soft start
Working & Storage	Operating temperature：-25~60℃；Operating humidity：0 ~ 85 % RH Storing temperature：-25 ~ 70℃；Storing humidity：0 ~ 95 % RH Applicable altitude range：＜1000m
Balancing	According to JB/T 9101-1999 requirements G6.3
Product Standards :	LVD EN60950-1 EMC EN61000-6-3,EN61000-4-2, EN61000-4-3
Mainly Applications	AUH/ AIR PURIFIER / Server Cooling & Ventilation / Grow Tent / Medical equipments/Ventilation SYSTEM/ Equipments Cooling / Refrigerator ,etc;ventilation fan cooling;ventilation exhaust fans

Additional information

Blade Material	STAINLESS STEEL
speed	2800rpm, 2600RPM, 2450RPM
customized support	OEM, ODM, OBM
mounting	FREE STANDING
place of origin	Zhejiang, China
brand name	LONGWELL
model number	LWBE3G355
warranty	1 Year
After-sales Service Provided	Video technical support
Type	centrifugal fan
Impeller material	Aluminum alloy
Direction	Clockwise
Bearing	Ball Bearing
Motor type	EC external rotor motor
Amb,Temp	-25 to +60℃
Protection	Tech out put /Over voltage protection /Over loading protection
Application	HVAC,air purifier , AHU
Voltage	230V,400V
Keyword	EC centrifugal fan
Selling units	Single item
Single package size	50X50X50 cm
Single gross weight	20.000 kg
