Description
Technical Description
| Material | Metal |
| Type of Protection | IP54 |
| Insulation Class | F |
| Mode of Operation | S1 |
| Bearing | Maintenance-free ball bearings |
Nominal data
| Type of Voltage | EC |
| Diameter of Roto | 92mm |
| Nominal Voltage | 230V |
| Frequency | 50/60Hz |
| Current | 0.6A |
| Power Input | 80W |
| Speed | 1300RPM |
| Static Pressure(Max) | 536Pa |
| Air Flow(Max) | 855m³/h |
| Noise | 59dB(A) |
| Min.ambient Temp | -30℃ |
| Max.ambient Temp | 60℃ |
