ebm-papst 4414 F Replacement Option — LONGWELL LWAD12025
Looking for a replacement or substitute for the ebm-papst 4414 F DC axial compact fan? The LONGWELL LWAD12025 series is a DC axial compact fan of a similar size. This page lists the published core parameters of both fans side by side — size, airflow, pressure, airflow style and supply — so you can shortlist a model; it does not state that the two fans are interchangeable. Catalogue ratings, curves and drawings are on the LONGWELL Fan Selector, and final selection is made at your duty point.
4414 F
LWAD12025
Core Specification Comparison
| Specification | ebm-papst 4414 F | LONGWELL LWAD12025MH-03 |
|---|---|---|
| Airflow style | DC axial compact fan | DC axial compact fan |
| Size | 119 × 119 × 25 mm | 120 × 25 mm |
| Max. airflow | 168 m³/h | 170 m³/h |
| Max. static pressure | approx. 55 Pa (read from the manufacturer curve) | 67 Pa |
| Input power | 5 W | 19.2 W |
| Speed | 2,900 rpm | 3,000 rpm |
| Supply | 24 V DC (12–28 V range) | 24 V DC |
| Noise | 43 dB(A) | 43.7 dB(A) |
| Sample lead time | Per manufacturer quotation | 1–3 days |
| Series lead time (≤500 units) | Per manufacturer quotation | 15–30 days |
| Pricing | Per manufacturer quotation | Quoted per project |
Reference-model data: ebm-papst datasheet 4414 F (nominal data and air-performance curve). Values approximate where marked. LONGWELL data: nameplate values from the LONGWELL Fan Selector. Maximum airflow and maximum pressure are measured at different operating points and never occur together.
LWAD12025 at a glance
Production Lead Time
Pricing
Size
Before using it as a substitute: what to check
Airflow is similar; the LONGWELL model has a higher published static pressure and a higher input power. Check the power budget of your supply.
Mechanical
The LWAD12025 housing size, mounting-hole pattern, guard and cable exit are given on the LONGWELL dimensioned drawing. Compare them with the installed ebm-papst 4414 F before ordering.
Electrical & control
Check the rated voltage, frequency and wiring of the selected LONGWELL model on its datasheet against your supply (24 V DC (12–28 V range) for the reference model).
Performance
The figures above are nameplate maxima from each manufacturer's own test conditions. We check your duty point (airflow at the real system pressure) against the LONGWELL curve before quoting.
Typical Applications
Fans of this type and size are typically used in:
- Electronics and control cabinet cooling
- Power supplies and inverters
- Telecom and server equipment
- Medical and laboratory equipment
FAQ
Is there a replacement for the ebm-papst 4414 F?
What should I check before using LWAD12025MH-03 in place of 4414 F?
What is the LONGWELL lead time?
How is LONGWELL pricing determined?
Evaluate LWAD12025 as a substitute for the ebm-papst 4414 F — samples in 1–3 days
Send a quick request — model + quantity + delivery address. Sample unit ships in 1–3 days for field validation. Series production at 15–30 day lead time after PO.
