Description
Technical Description
| Impeller Material | Plastic PA66 |
| Type of Protection | IP54 |
| Insulation Class | F |
| Mode of Operation | S1 |
| Bearing | Maintenance-free ball bearings |
Nominal data
| Type of Voltage | AC |
| Diameter of Rotor | 72mm |
| Nominal Voltage | 230V |
| Frequency | 50Hz |
| Current | 0.12/0.1A |
| Power Input | 28/22W |
| Speed | 630/422RPM |
| Static Pressure(Max) | 100/68Pa |
| Air Flow(Max) | 165/103m³/h |
| Noise | / |
| Min.ambient Temp | -30℃ |
| Max.ambient Temp | 60℃ |
Curves
Drawing
