Description
Technical Description
| Technical Feature | 1.High pressure and low vibration.Laser cutting blanking greatly improves the accuracy of the product,and the shape is beautiful and generous. 2.YE series of high-efficiency and energy-saving motors are used in the motor,with high efficiency,low energy consumption,good quality and long service life. 3.Widely used for conveying materials,air and non-corrosive,non-spontaneous combustion,non-viscous gases 4.Especially suitable for high-pressure forced ventilation in general exercise,glass, ceramics,radio,electroplating,batteries and other industries,as well as grain,feed,etc.Material conveying in mineral powder,plastics,chemical industry and boiler industry. 5.Optional high temperature resistant extended shaft motor,high temperature resistant 200℃. |
Nominal data
| Dimensions | / |
| Voltage | 380V/380V/380V |
| Frequency | 50Hz/50Hz/50Hz |
| Power | 18.5KW-2/22KW-2/30KW-2 |
| Speed | 2900r/min/2900r/min/2900r/min |
| Total Head | 9149-9055Pa/9003-8601Pa/8857-8148Pa |
| Air Flow | 3220-5153m³/h/4455-6066m³/h/5690-6978m³/h |
| Noise | / |
Curves
Drawing
Download
